ModelXP-1200.1
TypeClass-D Mono Car amplifier
RMS Power Ratings
1CH1ohm1200 Watt
1CH2ohm650 Watt
1CH4ohm450 Watt
T.H.DTested Voltage & THD : 14.4V & Less Than 1% THD
Signal to Noise > 90db
High-Pass
Low-Pass25Hz~250Hz
Damping Factor+350
Bass Boost0 ~ 6 dB
Variable Phase Shift0 ~ 180 degrees
Double Sided Through Hole Epoxy PCBFR 4 PCB
Input Sensitivity200mv~6v
Fuses Rating20A*4
Dimension(M M) Length(320 mm) * width (260 mm) * height (55 mm)
weightNet Weight5.5 kg
Gross weight6 kg
